| CE-6000 Series Detailed Specifications | ||
| 1. Model Information | ||
| Material Code | CE-6002n-60V100A-H | |
| 2. Channel Information | ||
| Channel Quantity | Channels per unit | 2 |
| Channel Control | Control Mode | Independent Control |
| Parallel Mode | Support max 4 channels parallel (Pulse/SIM disabled in parallel) | |
| 3. Power Grid Side Parameters | ||
| Input Power | AC380V ± 15% 50/60 ± 5Hz | |
| Power Factor | ≥99% (Full Load) | |
| System Efficiency | 90% (Max) | |
| 4. Functions and Performance | ||
| Voltage Range | Charge: 0V~60V | Discharge: 3V~60V |
| Voltage Accuracy | ±0.02% of FS (24bit Resolution) | |
| Current Range | 0.5A ~ 100A | Accuracy: ±0.05% of FS |
| Response Time | Current Response: ≤3ms | Conversion: ≤6ms |
| Modes | Charge: CCC, CVC, CC-CVC, CPC | Discharge: CCD, CVD, CPD, CRD |
| 5. Communication & Management | ||
| Protocol | TCP/IP via Ethernet | Baud Rate: 10M~100M Adaptive |
| Data Management | MySQL Database | Export: Excel, Txt |
